FEATURES AND FUNCTIONS-
SPECIFICATIONS-
- 6-Channel, Full Range, Class A/B
- SQ Upgrades: Op-amps, Caps, Etc.
- Tiffany style Panel Mount RCA’s
- RCA and Speaker Level Inputs
- Variable input gain control
- Variable electronic crossover
- Auto-on with Speaker level inputs
- 2/4/6 Ch. input mode selector
- Compact chassis
- Variable bass boost control
SPECIFICATIONS-
- Power @ 4Ω: 6 x 100 watts
- THD @ Rated Power < 0.5% THD
- Power @ 2Ω: 6 x 150 watts
- Power Bridged @ 4Ω: 3 x 300W RMS
- Signal to Noise Ratio > 95dB
- THD + Noise < 0.05%
- Channel Separation >60dB
- Frequency Response 15Hz to 30KHz ±1dB
- Input Sensitivity .25v to 5v
- Dimensions in mm: 160(W) x 52(H) x 452(L) Overall: 160(W) x 52(H) x 488(L)
