PRODUCT DESCRIPTIONS-
– QUALIDADE DE ÁUDIO 4K – Ultra HD
Alta Fidelidade Sonora, Médios mais Definidos, Agudos mais Nítidos.
– Crossovers
Low Pass: 60Hz ~ 22KHz
High Pass: 10Hz ~ 700Hz
– Fonte Reforçada para GRAVES MAIS FORTES
– CONECTORES ROBUSTOS
Com Guia de Isolamento de Cabo (GIC)
– Versatilidade na Instalação
Subwoofers
Woofers
Kits Originais / 6″ / 6×9″
Kits 2 Vias
Subwoofers
Associação de Drivers e Tweeters
NOVA TECNOLOGIA MAIS COMPACTO
Technical Specifications-
| CHARACTERISTICS | IR400.1 |
| Number of Channels | 1 |
| RMS Power at 2 Ohm 13.8V | 400W |
| RMS Power at 4 Ohm 13.8V | 160W |
| RMS Power at 2 Ohm 14.4V | 430W |
| RMS Power at 4 Ohm 14.4V | 250W |
| Supply Voltage | 9V ~ 15V |
| Frequency Response | 10Hz ~ 22KHz |
| Crossover Low Pass | 60Hz ~ 22KHz |
| Crossover High Pass | 10Hz ~ 700Hz |
| Signal to Noise | > 90dB |
| Harmonic Distortion | < 0,01% |
| Input Sensitivity | RCA: 200mV / FIO: 1.5V |
| Input Impedance | RCA: 38K Ohms / FIO: 10K Ohms |
| Impedance Output | 2 OHMS |
| Consumption with Signal Musical | 18A (13.8V) |
| Consumption with Signal Bass | 36A (13.8V) |
| Dimensions (H x W x D) mm | 52,5 x 99,8 x 127,5 |
| Weight Kg | 508 g |
