PRODUCT DESCRIPTIONS-
– 4K AUDIO QUALITY – Ultra HD
High Sound Fidelity, Clearer Mids, Clearer Treble.
– BASS BOOST 14dB feature at 45Hz
Enhanced power supply for STRONGER GRAVES
– ROBUST CONNECTORS
With Cable Insulation Guide (GIC)
– Easy Installation
Original Kits / 6 ″ / 6 × 9 ″
2 Way Kits
Subwoofers
Drivers and Tweeters Association
Small Size. NEW TECHNOLOGY
Technical Specifications-
| CHARACTERISTICS | IR400.4 |
| Number of Channels | 4 |
| RMS Power at 2 Ohm 13.8V | 4 x 100 WRMS |
| Power @ 13.8V Bridge 4 Ohms | 2 x 200 WRMS |
| Supply Voltage | 9 ~ 15V |
| Frequency Response | 10Hz ~ 24KHz |
| Crossover Low Pass | 90Hz |
| Crossover High Pass | 90Hz |
| Signal to Noise | > 90 dB |
| Harmonic Distortion | Distorção harmônica total (THD +N 1W @ 4Ω): < 0,01 % |
| Input Sensitivity | 200 mV |
| Input Impedance | 20K OHMS |
| Impedance Output | STEREO: 2 OHMS / BRIDGE 4 OHMS |
| Consumption with Signal Musical | 17A |
| Consumption with Signal Bass | 33,5A |
| Dimensions (H x W x D) mm | 52,5 x 127,5 x 99,7 |
| Weight Kg | 0,52 |
