PRODUCT DESCRIPTIONS-
Technical Specifications-
| CHARACTERISTICS | HL 1200.4 – 2 OHMS |
| Number of Channels | 4 |
| RMS Power at 2 Ohm 12.6V | 4 x 300W RMS |
| RMS Power at 4 Ohm 12.6V | 4 x 165W RMS |
| RMS Power at 2 Ohm 13.8V | 4 x 320W RMS |
| RMS Power at 4 Ohm 13.8V | 4 x 170W RMS |
| Power @ 12.6V Bridge 4 Ohms | 2 x 600W RMS |
| Supply Voltage | 9 ~ 15V |
| Frequency Response | 10Hz ~ 26 KHz |
| Crossover Low Pass | 90Hz |
| Crossover High Pass | 90Hz |
| Signal to Noise | > 90 dB |
| Harmonic Distortion | < 0,4 % THD |
| Input Sensitivity | 0,2V |
| Input Impedance | 14K OHMS |
| Impedance Output | 2 OHMS |
| Consumption with Signal Musical | 53A |
| Consumption with Signal Bass | 106A |
| Dimensions (H x W x D) mm | 66 x 206 x 216 mm |
| Weight Kg | 1.95KG |
