PRODUCT DESCRIPTIONS
| CHARACTERISTICS | HL 800.4 – 2 OHMS |
| Number of Channels | 4 |
| RMS Power at 2 Ohm 12.6V | 4 x 225W RMS (STEREO) |
| RMS Power at 4 Ohm 12.6V | 4 x 140W RMS (STEREO) |
| RMS Power at 2 Ohm 13.8V | 4 x 260W RMS (STEREO) |
| RMS Power at 4 Ohm 13.8V | 4 x 165W RMS (STEREO) |
| Power @ 12.6V Bridge 4 Ohms | 2 x 450W RMS |
| Power @ 13.8V Bridge 4 Ohms | 2 x 520W RMS |
| Supply Voltage | 9,5 ~ 15V |
| Frequency Response | 10Hz ~26KHz |
| Crossover Low Pass | 90Hz |
| Crossover High Pass | 90Hz |
| Signal to Noise | > 90 dB |
| Harmonic Distortion | < 0,4 % THD |
| Input Sensitivity | 0,2V |
| Input Impedance | 14K OHMS |
| Impedance Output | STEREO 2 OHMS / STEREO 4 OHMS |
| Consumption with Signal Musical | 44A |
| Consumption with Signal Bass | 88A |
| Dimensions (H x W x D) mm | 66 x 206 x 206 mm |
| Weight Kg | 1.70KG |
