PRODUCT DESCRIPTION-
GENERAL SPECIFICATION
| 1600.1 EVO 5 - 1 OHM | Power @ 1Ω: 1 X 1600 WRMS Power @ 2Ω: 1 X 1056 WRMS Power @ 4Ω: 1 X 697 WRMS |
| Response Frequency (-3dB) | 5Hz ~ 25kHz |
| Subsonic Filter | 5Hz ~ 80Hz |
| Low Pass Filter | 50Hz ~ 1kHz |
| Bass Boost | 0dB ~ 12dB @ 50Hz |
| Power Voltage | 9V ~ 16V |
| Signal-Noise Ratio | 1Ω: 93.7dB 2Ω: 95dB 4Ω: 93.4dB |
| Input Sensitivity | 0.2V ~ 2V |
| Music Consumption | 1Ω: 75A 2Ω: 71A 4Ω: 69.4A |
| With Resistive Load | 1Ω: 149A 2Ω: 143A 4Ω: 138.8A |
| Total Efficiency | 1Ω: 85% 2Ω: 89% 4Ω: 91.5% |
|
Damping Factor
|
>2000 |
| Power cable | 16mm² (5 AWG) |
| Audio Output Cable | 2 x 1.5 mm² (15 AWG) |
| Recommended Fuse (Musical) | 80A |
| Recommended Drums (Minimum for Musical Use) | 80 Ah |
| Width | 13.6 cm |
| Length | 18 cm |
| Height | 5.48 cm |
| Weight | 1.13 kg |
