PRODUCT DESCRIPTION-
GENERAL SPECIFICATIONS
|
800.1 EVO 5 - 2 OHMS
|
RMS Power @ 2Ω: 800W RMS Power @ 4Ω: 528W RMS Power @ 8Ω: 348W |
|
Response frequency
|
5Hz ~ 1000Hz |
|
Subsonic Filter (HP 12dB/8)
|
5Hz ~ 80Hz |
| Low Pass Filter (LP 12dB/8) | 50Hz ~ 1000Hz |
| Power Voltage | 8V ~ 16V |
| SNR | 93dB |
| Input Sensitivity | 0.2V ~ 4V |
| Consumption With Musical Signal | 36A |
| Consumption With Resistive Load (1kHz @ 12.6V) | 72A |
| Total Efficiency | 88% |
| Damping Factor (@100Hz Rated Impedance) | 200 |
| Minimum Audio Output Impedance | 2Ω |
| Power cable | 10mm² (7AWG) |
| Audio Output Cable | 2 x 2mm² (12 AWG) |
| Recommended Fuse (Musical) | 40A |
| Recommended Drums (Minimum for Music Use) | 60Ah |
| Width | 11.3 cm |
| Length | 14.8 cm |
| Height | 5.1 cm |
| Weight | 0.7 KG |
