PRODUCT DESCRIPTION-
| Dynamic Range(RCA Input) | ≥100dB |
| S/N(RCA Input) | ≥90dB |
| THD | ≤0.05% |
| Frequency Response | 20Hz~20KHz |
| Input Impedance | High Level Input:240Ω |
| Low level Output Impedeance | 51Ω |
| Signal Input Range | RCA :7.5Vpp;High Level:26Vpp |
| Signal Output Range | RCA :8Vpp;Amplifier Maximum Power:4CH×50W+4CH×80W+2CH×160W,Bridging 1×300W |
| Working Temperature | -20-70℃ |
| Power | DC9V-16V |
| REM Input | High Level Input Signal:H1+/H1-or ACC control cable |
| REM Output | +12V Start up Voltage Output |
| Standby Power | ≤0.1W |
| Gross Weight | Approx. 2.08kg |
| Product Dimension(L×H×W) | 255×175×47mm |
Technical:
| Input Type | 6 Channel high level,2 Channel Low Level,External digital Bluetooth,Optical coaxial |
| Output Type | 12 Channels low level,4CH×50W+4CH×80W+2CH×160W,Bridging 1×300W |
| Output Gain | Gain range:Mute,-59.9dB~0.0dB |
| Output Signal EQ | 31 band Equalizer Engine, |
| 1.Frequency Range:20Hz~20KHz,1Hz Accuracy | |
| 2.Q value(Slope):0.404~28.85 | |
| 3.Gain:-12.0dB~+12.0dB,0.1dB Accuracy | |
| Output Signal Crossover | Each output is equipped with multi-order high and low pass indepance filters. |
| 1.Filtering types:Link-Rill,Butter-W, Bessel | |
| 2.Filtering frequency division point:20Hz~20kHz,Resolution 1Hz | |
| 3.Filter slope(Slope) setting:6dB/Oct to48dB/Oct and OFF | |
| Output Phase and Time Alignment | Each output channel can be adjusted for phase and delay,parameter range : |
| phase:in-phase or reverse-phase(0°/180°); | |
| Delay: 0.000 to 20.000 ms, 0 to 692 cm,0 to 273 inch. | |
| Presets | Save 6 presets into the device. |
