PRODUCT DATA
| Dynamic Range(RCA Input) | ≥100dB |
| S/N(RCA Input) | ≥90dB |
| THD | ≤0.05% |
| Frequency Response | 20Hz~20 KHz |
| Input Impedance | Low level:20KΩ;High level :51Ω |
| Low Level Output Impedance | 51Ω |
| Signal Input Range | RCA :5.5Vpp;High level:26Vpp |
| Power | DC 9V~16V |
| REM Input | High level input signal :Fl+/FL-or ACC control cable |
| REM Output | +12V Strat up voltage output |
| Standby Power | ≤0.1W |
| Net Weight | Approx. 0.85kg |
| Product Dimension | 176(L)*141.2(W)*39(H)mm |
TECHNICAL SHEET
| Input Type | 4 Channel high level,4 channel low level,support built-in Bluetooth,support U disk playback external wiring controller |
| Output Type | 8 Channels low level,4 CH×50W power |
| Output Gain | Gain range:Mute,-59.9dB~0.0dB |
| Output Signal EQ | 31 band Equalizer Engine, |
| 1.Frequency Range:20Hz~20KHz,1Hz Accuracy | |
| 2.Q value(Slope):0.404~28.852 | |
| 3.Gain:-12.0dB~+12.0dB,0.1dB Accuracy | |
| Output Signal Crossover | Each output is equipped with multi-order high and low pass indepance filters. |
| 1.Filtering types:Link-Rill,Butter-W, Bessel | |
| 2.Filtering frequency division point:20Hz~20kHz,Resolution 1Hz | |
| 3.Filter slope(Slope) setting:6dB/Oct to48dB/Oct and OFF | |
| Output Phase and Time Alignment | Each output channel can be adjusted for phase and delay,parameter range : |
| phase:in-phase or reverse-phase(0°/180°); | |
| Delay: 0.000 to 20.000 ms, 0 to 692 cm,0 to 273 inch. | |
| Presets | Save 6 presets into the device. |
