PRODUCT DESCRIPTION-
Designed for true bass enthusiasts, the WDX6.5G2R.4 subwoofers offer unmatched power and precision. • Featuring a custom mounting gasket for a perfect seal, eliminating rear-canceling waves for pure bass. • All-new dust caps and a custom-tooled aluminum basket provide durability, rigidity, and optimal heat dissipation. • The custom ribbed surround and High Excursion motor with Y35 ferrite magnets and high-temperature voice coils deliver deep, distortion-free bass. • Built for Bass: Power handling up to 1500 watts dynamic (750 watts nominal) • The WDX6.5G2R.4 sets a new standard for earth-shaking bass. Ready to feel the difference?
Features
Our engineers at DB Drive have designed this subwoofer from the ground up to shake the ground up. The double-stitched foam surround and die-cast aluminum vented basket allow for maximum excursion, while the protective magnet cover gives the woofer a rugged yet stylish appearance.
1.5" BASV High-Temperature Voice coil
- Non-pressed paper cone
- Double stitched foam surround
- Dual poly-cotton dampeners
- Die-cast aluminum vented basket
- Rubber gasket trim ring
- Large gauge compression terminals
- Protective magnet cover
Specifications
| Structure | 6.5" (16.51cm) Woofer |
|---|---|
| Dynamic Power Handling | 600 Watts |
| Nominal Power Handling | 300 Watts |
| Impedance | Dual 4Ω Voice Coil |
| PARAMETERS | |
| Resonant Frequency (fs) | 58.94Hz |
| D.C. Voice Coil Resistance (Re) | 3.2 x 3.2Ω |
| Mechanical Quality Factor (Qms) | 4.065 |
| Electrical Quality Factor (Qes) | 0.823 |
| Total Quality Factor (Qts) | 0.684 |
| Equivalent Air Volume to Cms (Vas) | 2.749 L |
| Mass of Diaphragm/Coil (Mms) | 77.157 g |
| Force Factor (Bl) | 7.453 |
| Sound Pressure Level (SPL) | 80.2 dB |
